Single Shake Nursing Bed: Care Starts Here

A single shake nursing bed is a practical bedding designed specifically for nursing needs.

Name: Manual one cranks hospital bed

Model: HR-S31

Size: L2050*W960*H500mm

product details

Product Parameters

Product Name	Manual single shaker
key word	Manual nursing bed
Model	HR-D31
size	L2050W960H500mm.
function	1 functions
Bedhead and Bedend	Reinforced plastic
Work load	200 kilograms
Control method	Manual
Caster wheels	Silent wheel
Specific purpose	Medical bed
colour	Standard or customized
OEM/ODM	accept
Minimum order quantity	1 set

Main features

Single Shake Nursing Bed Care Starts Here (8)khs

1. Safe working load: 200kg.

2. The back board folding angle: 0~75 °.

3.Guardrail:

1) One guardrail in each side of bed.

2) It can be automatically locked when raising, and each guardrail can bear more than 50KG.

3) Guardrail safety switch design, placed under the guardrail to avoid misuse of the patient.

Single Shake Nursing Bed Care Starts Here (2)w7f

Single Shake Nursing Bed Care Starts Here (3)uwd

4.Casters

1)The four casters are silent.

2)Steel structure, precision ball bearings are placed in the rotating head and the caster, the caster frame is equipped with a wheel cover made of synthetic material, suitable for locking the lever with a cam hole. Caster surface material: polyurethane, single dynamic (force) load is not more than 175 kg, static load is not more than 200 kg.

3)Braking system: Pedal-type synchronous braking arms on both sides of the bed, adopting all-metal structure, compact structure and reliable braking.

5. At the 4 corners of the bed, there is an diameter HDPE anti-collision wheel which inter gated on H/F board.

6. There are 1 hook in each side for drainage bag.
