Electric five function home care bed, guarding family health with love

Electric five function home care bed brings intimate care to your life. This nursing bed is designed specifically for home environments, combining practicality and comfort.

Product Material:
In terms of product material, the bed body is made of high-quality cold-rolled carbon steel pipes with a specification of 60 × 30 × 1.2mm. The bed panel is made of high-quality cold-rolled carbon steel plate with a thickness of 1.0mm, which greatly improves the strength of the bed panel, makes its stress more balanced, and significantly enhances its resistance to pressure. The bed board has breathable holes and anti slip function. Steel pipes are welded under the bed board for reinforcement, making it solid and durable. The bed legs are also made of high-quality cold-rolled carbon steel pipes, with specifications of 60 × 30 × 1.2mm.

product details

Product Parameters

Product Name	Electric five function home care bed
key word	Multi functional nursing bed
Model	HR-DJ06
size	Length: 2050mm, width: 1020mm, height: 480-760mm. The bed tilts back and forth: 12 ± 2 degrees.
function	5 functions
Bedhead and Bedend	Wooden materials
Work load	240kilograms
Timed turnover period
Control method	electric
Caster wheels	High end casters
Specific purpose	Home care bed
colour	Standard or customized
OEM/ODM	accept
Minimum order quantity	1 set

Product Details

Guardrail

The high-quality solid wood guardrail is made of sturdy material, with a thick and heavy style, easy to operate, easy to clean, environmentally friendly and odorless. The product will not have paint peeling or peeling after long-term use. The guardrail lifting adopts aluminum alloy sliding track and high-quality hardware accessories, with a long service life and smooth, fluent and safe lifting process.

Electric Machinery

The product is equipped with four sets of motors. These motors are always thrust oriented and have the characteristics of uniform force distribution and stable power. Among them, the lifting function is managed by a motor, the bending leg function is managed by a motor, the back knee linkage function is managed by a motor, and the overall lifting function is also managed by a separate motor. Each motor is dedicated to one function, effectively extending the service life of the motor.

There are drip rack sockets diagonally on the bed frame, and drainage urine bag hooks are placed on both sides of the bed frame. The drip rack can be placed at the bottom of both sides of the bed frame when not in use.

Wheels

Adopting high-end casters, independent braking, built-in fully enclosed self-lubricating bearings, no need for refueling maintenance, preventing foreign objects from getting involved, independent braking; The wheel surface is made of TPR polymer wear-resistant material, which is wear-resistant and noise free.

Spray

The entire bed is treated with dual phosphating and electrostatic powder coating. The bed coating adopts antibacterial coating, which is resistant to bacteria, bacteria, acid and alkali corrosion, and discoloration, effectively extending the service life.
